2×1G + 2×10G Security Gateway · 1U

Your first dedicated security box — a home-lab security gateway at the edge that drops unwanted traffic before it reaches your servers. Switch on intrusion-blocking and flood-absorb as paid add-ons when you need them.

Front view of 2×1G + 2×10G Security Gateway · 1U

Technical profile

NGFW. WAN + LAN each carry a 1G RJ45 + a 10G SFP+ (11 Gbps/side), ~20 Gbps forwarding ASIC / ~2 Gbps inspected. Cable the 1G RJ45 on each side at the garage tier (matches the edd + switch); step up to the 10G SFP+ as you grow. Inspection (2G) is fed through either side. Stateful firewall base; IPS + Scrub are on-box licenses (capex + monthly). Runs on its own silicon — unlike a gateway add-on it doesn't throttle your router.

Technical specifications

SpecificationValueDetails
Rack height1U
Power~80 W
PSU count1
Forwarding capacity~20 Gbps
Inspection capacity~2 GbpsThe inspection engine is a separate and lower throughput ceiling.

Port overview

CountConnectorSpeedPurposeColor
RJ451 GbpsWANYellow
SFP+10 GbpsWANYellow
RJ451 GbpsLANBlue
SFP+10 GbpsLANBlue

Pricing

ItemTypeOne-timeMonthlyDetails
2×1G + 2×10G Security GatewayHardware$4,000$131
IPS / ThreatOptional software upgrade$200$60Adds on-box intrusion detection and prevention.
ScrubOptional software upgrade$250$80Adds on-box volumetric DDoS mitigation.

Availability

ModeMaps
GarageBasementSmall Colocation
SANDBOX
